Electronic Engine Speed Controller Governor Esd5500e For Generator
Genset Parts
USD $28.32
Condition : New
Free Shipping
Notify me when the price drops
We will email you if we find a lower price on this product!
Description:
Environmental: Ambient Operating Temperature Range -40°c to +85°c, Relative Humidity up to 95%, Storage Temperature -55°c ~ 90°c, Shock 20-100HZ 500mm/Sec.
Supply: 12 or 24V DC Battery Systems(Transient and Reverse Voltage Protected)
Polarity: Negative Ground(Case Isolated)
Power Consumption: 50mA continuous plus actuator current
Actuator Current Range @ 25°c-(Inductive Load)
Min. 2.5 Amps, Max. 10 Amps continuous
Speed Sensor Signal: 0.5-120 V RMS
Speed Switch Relay Contacts(N.O.and N.C.)
10Amp
Feature:
High performance,reliable quality
We work with every effort to provide quality products and professional service.
Specification:
Isochronous Operation/Steady State Stability
± 0.25% or better
Speed Range/Governor
1K-7.5K Hz continuous
Speed Drift with Temperature
± 1% Maximun
IDLE Adjustment
160 ± 20Hz ~ 60% of set speed
Droop adjustment Min.(K-L Jumpered)
15Hz. ± 6Hz. per 1.0 A change
Droop adjustment Max.(K-L Jumpered)
400Hz. ± 75Hz. per 1.0 A change
Droop Adj. Max. (K-L Jumpered)
875Hz., ± 75Hz. per 1.0 A change
Droop Adj. Min. (K-L Jumpered)
15Hz., ± 6Hz. per 1.0 A change
Speed Trim Range
± 200Hz.
Remote Variable Speed Range
500 -7.5Hz. or any part thereof
Terminal Sensitivity
J: 100Hz., ± 15Hz/Volt @ 5.0 K Impedance
L: 735Hz., ± 60Hz/Volt @ 65 K Impedance
N: 148Hz., ± 10Hz/Volt @ 1Meg. Impedance
P: 10V DC Supply @ 20ma Max.
Speed Switch Adjustment Range
1000-10000Hz.
About Delivery:
We have warehouses in California and New Jersey
We will follow the principle of nearest delivery
When one warehouse is out of stock, it will be shipped from another warehouse
Thank you for your understanding
Package Product List:
1 × Engine Speed Governor Controller ESD5500E
1 × product Instructions
Item SpecificsBrand marddpairMPN ESD5500ECompatible Model Speed ControllerType Engine Speed ControllerWarranty 1YearEquipment Type Voltage RegulatorModel Voltage RegulatorCustom Bundle NoBundle Description NoModified Item No
